UC3842BD
1A 47kHz~57kHz 8V~30V Flyback 5V SOP-8 AC DC Converters, Offline Switchers RoHS
SOP-8ROHS CompliantActive
Current-Mode PWM Controllers
- Manufacturer
- COSINE
- Manufacturer part #
- UC3842BD
- Store part #
- C22458872
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,265 in stock
#C22458872
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.62 | ₹78.10 |
| 50+ | ₹14.10 | ₹705.00 |
| 150+ | ₹13.35 | ₹2,002.50 |
| 500+ | ₹12.78 | ₹6,390.00 |
| 2,500+ | ₹12.33 | ₹30,825.00 |
| 4,000+ | ₹12.11 | ₹48,440.00 |
5 × ₹15.62
₹78.10
excl. GST
₹92.16 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
UC3842BD
₹78.10 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+125℃
- Output Current
- 1A
- Frequency - Switching
- 47kHz~57kHz
- Voltage - Supply
- 8V~30V
- Features
- Under-voltage lockout;Under Voltage Protection;Over Current Protection
- Topology
- Flyback
- Output Voltage
- 5V
- Duty Cycle(Max)
- 100%
- Feedback System
- Secondary-Side Feedback
- Working Mode
- PWM Modulation
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.188 g
Overview
The COS UC384x series of controllers are peak current mode pulse width modulators. They are designed to offer improved performance and lowered external parts count when used in designing off-line or DC-to-DC switching power supplies. The internally implemented circuits include an under-voltage lockout (UVLO), featuring a start-up current of less than 1mA, and a precision reference trimmed for accuracy at the error amplifier input. Other internal circuits include logic to ensure latched operation, a pulse-width modulation (PWM) comparator that also provides current-limit control, and a totem-pole output stage that is designed to source or sink high-peak current. The output stage, suitable for driving N-channel MOSFETs, is low when it is in the off state.
Applications
- Solar Inverters
- Switching Regulators of Any Polarity
- Motor Control
- Battery Chargers
- DC/DC Power Supplies
Key features
- 8-V to 30-V Operation
- Low Start-up Current: <1mA
- 5.1-V Reference Trimmed to 1%
- Current Mode Operation up to 500KHz
- Automatic Feed-forward Compensation
- Under-voltage Lockout With Hysteresis Latching PWM for Cycle-by-Cycle Current Limit
- Double-Pulse Suppression
- High Current Output Driver Optimized for off-line and DC-to-DC Converters
- Available Packaging: SOP8/TSSOP8/DIP8
