VBsemi ElecDatasheet (PDF)
VB162KX
N-Channel 60V 700mA 1.55W Surface Mount SOT-23(TO-236)
SOT-23(TO-236)RoHSActive
MOSFET N-CH 60V 700mA SOT-23(TO-236)
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- VB162KX
- Store part #
- C516876
- Package / case
- SOT-23(TO-236)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50 in stock
#C516876
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.18 | ₹91.80 |
| 100+ | ₹7.61 | ₹761.00 |
| 300+ | ₹6.83 | ₹2,049.00 |
| 3,000+ | ₹4.80 | ₹14,400.00 |
| 6,000+ | ₹4.33 | ₹25,980.00 |
| 9,000+ | ₹4.09 | ₹36,810.00 |
10 × ₹9.18
₹91.80
excl. GST
₹108.32 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
VB162KX
₹91.80 for 10 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 700mA
- Pd - Power Dissipation
- 1.55W
- RDS(on)
- 910mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 3nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.054 g
Overview
Key features
- Compliant with halogen-free standard as defined by IEC 61249-2-21
- 100% Rq and UIS tested
- Trench power MOSFET
- RoHS compliant per directive 2002/95/EC
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | AFN2330S23RG-VB#C29779568VBsemi Elec · SOT-23(TO-236) | VBsemi Elec | SOT-23(TO-236) | 50 | ₹29.09 · 50 in stock | View |
 | QM0008J-VB#C29779572VBsemi Elec · SOT-23(TO-236) | VBsemi Elec | SOT-23(TO-236) | 20 | ₹29.09 · 20 in stock | View |
 | TSM2328CX RFG-VB#C29779576VBsemi Elec · SOT-23(TO-236) | VBsemi Elec | SOT-23(TO-236) | 5 | ₹36.37 · 5 in stock | View |
 | DTS6400-VB#C22389362VBsemi Elec · SOT-23(TO-236) | VBsemi Elec | SOT-23(TO-236) | 130 | ₹34.44 · 130 in stock | View |
 | DTS6410-VB#C41370190VBsemi Elec · SOT-23(TO-236) | VBsemi Elec | SOT-23(TO-236) | 5 | ₹30.84 · 5 in stock | View |
