VBP16R20SE
N-Channel 600V 20A 160W Through Hole TO-247AC
TO-247ACRoHSActive
MOSFET N-CH 600V 20A TO-247AC
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- VBP16R20SE
- Store part #
- C46527850
- Package / case
- TO-247AC
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5 in stock
#C46527850
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹506.14 | ₹506.14 |
| 10+ | ₹450.63 | ₹4,506.30 |
| 30+ | ₹289.54 | ₹8,686.20 |
| 90+ | ₹253.83 | ₹22,844.70 |
| 600+ | ₹237.94 | ₹1,42,764.00 |
| 900+ | ₹230.76 | ₹2,07,684.00 |
1 × ₹506.14
₹506.14
excl. GST
₹597.25 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 30 per tube
VBP16R20SE
₹506.14 for 1 + GST
Specifications
- Drain to Source Voltage
- 600V
- Operating Temperature
- -55℃~+150℃
- Output Capacitance(Coss)
- 330pF
- Current - Continuous Drain(Id)
- 20A
- Ciss-Input Capacitance
- 2.3nF
- Pd - Power Dissipation
- 160W
- RDS(on)
- 150mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 62nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tube-packed
- Standard pack
- 30 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 8.32 g
Overview
Applications
- Server and telecom power supplies
- Switch mode power supplies (SMPS)
- Power factor correction (PFC)
- Lighting
- High intensity discharge (HID) lamps
- Fluorescent lamp ballast lighting
Key features
- Low figure of merit (FOM) Ron × Qg
- Low input capacitance (Ciss)
- Reduced switching and conduction losses
- Ultra-low gate charge (Qg)
- Avalanche energy rated (UIS)
