VESD01C1-02VHG3-08
6.9VC Clamp 14.6A@8/20us Ipp ESD DIODE SOD-523
SOD-523ROHS3 CompliantActive
ESD DIODE 1VWM 6.9VC SOD-523
- Manufacturer
- VISHAY
- Manufacturer part #
- VESD01C1-02VHG3-08
- Store part #
- C3707128
- Package / case
- SOD-523
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,390 in stock
#C3707128
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.36 | ₹76.80 |
| 50+ | ₹13.52 | ₹676.00 |
| 150+ | ₹12.73 | ₹1,909.50 |
| 500+ | ₹11.75 | ₹5,875.00 |
| 2,500+ | ₹9.90 | ₹24,750.00 |
| 5,000+ | ₹9.63 | ₹48,150.00 |
5 × ₹15.36
₹76.80
excl. GST
₹90.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 8,000 per reel
VESD01C1-02VHG3-08
₹76.80 for 5 + GST
Specifications
- Clamping Voltage
- 6.9V
- Peak Pulse Current (Ipp)
- 14.6A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 100W
- Number of Channels
- 1
- Voltage - Breakdown
- 2.5V
- type
- ESD
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 100uA
- Reverse Stand-Off Voltage (Vrwm)
- 1V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 8,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.018 g
Overview
Applications
- Single-line ESD protection
- Compact SOD-523 package
- AEC-Q101 qualified
- Operating range 1V to 33V
- ESD immunity per IEC 61000-4-2
- Lead-free soldering
- Automated optical inspection
- Green/eco-friendly
- Halogen-free materials
- RoHS compliant
- High-temperature operation (-55 to +150°C)
Key features
- COMPACT SOD-523 package
- Low package height < 0.7mm
- 1-line unidirectional ESD-protection
- AEC-Q101 qualified available
- Working range 1V to 33V
- ESD immunity acc. IEC 61000-4-2 ±15kV to ±30kV contact discharge, ±15kV to ±30kV air discharge
- Lead plating: Sn (e3) - soldering can be checked by standard vision inspection AOI = automated optical inspection
