STDatasheet (PDF)
VIPER27HN
115kHz 1W 8.5V~23.5V 800V Flyback DIP-7 AC DC Converters, Offline Switchers RoHS
DIP-7ROHS3 CompliantActive
Off-line high voltage converters
- Manufacturer
- ST
- Manufacturer part #
- VIPER27HN
- Store part #
- C2832857
- Package / case
- DIP-7
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,684 in stock
#C2832857
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹197.31 | ₹197.31 |
| 10+ | ₹162.40 | ₹1,624.00 |
| 50+ | ₹143.11 | ₹7,155.50 |
| 100+ | ₹121.20 | ₹12,120.00 |
| 500+ | ₹111.66 | ₹55,830.00 |
| 1,000+ | ₹107.33 | ₹1,07,330.00 |
1 × ₹197.31
₹197.31
excl. GST
₹232.83 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
VIPER27HN
₹197.31 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+150℃
- Frequency - Switching
- 115kHz
- Pd - Power Dissipation
- 1W
- Voltage - Supply
- 8.5V~23.5V
- Voltage - Breakdown
- 800V
- Features
- Soft-start;Over Voltage Protection;Overtemperature protection (OTP);Over Current Protection;Under Voltage Protection
- Topology
- Flyback
- Duty Cycle(Max)
- 80%
- Feedback System
- Secondary-Side Feedback
- Working Mode
- PWM Modulation
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.24 g
Overview
The device is an off-line converter with an 800 V rugged power section, a PWM control, two levels of over-current protection, overvoltage and overload protections, hysteretic thermal protection, soft-start and safe auto-restart after any fault condition removal. Burst mode operation and device very low consumption help to meet the standby energy saving regulations. Advance frequency jittering reduces EMI filter cost. Brown-out function protects the switch mode power supply when the rectified input voltage level is below the normal minimum level specified for the system. The high voltage start-up circuit is embedded in the device.
Applications
- Auxiliary power supply for consumer and home equipments
- ATX auxiliary power supply
- Low / medium power AC-DC adapters
- SMPS for set-top boxes, DVD players and recorders, white goods
- Off-line high voltage converters
Key features
- 800 V avalanche rugged power section
- PWM operation with frequency jittering for low EMI
- Operating frequency:
- 60 kHz for L type
- 115 kHz for H type
- Standby power <50 mW at 265 Vac
- Limiting current with adjustable set point
- Adjustable and accurate overvoltage protection
- On-board soft-start
- Safe auto-restart after a fault condition
- Hysteretic thermal shutdown
