ZXMN10A25GTA
N-Channel 100V 4A 3.9W Surface Mount SOT-223
SOT-223ROHS3 CompliantActive
MOSFET N-CH 100V 4A SOT-223
- Manufacturer
- DIODES
- Manufacturer part #
- ZXMN10A25GTA
- Store part #
- C212308
- Package / case
- SOT-223
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C212308
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹139.63 | ₹139.63 |
| 10+ | ₹113.70 | ₹1,137.00 |
| 30+ | ₹100.94 | ₹3,028.20 |
| 100+ | ₹87.98 | ₹8,798.00 |
| 500+ | ₹80.33 | ₹40,165.00 |
| 1,000+ | ₹76.51 | ₹76,510.00 |
1 × ₹139.63
₹139.63
excl. GST
₹164.76 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
ZXMN10A25GTA
₹139.63 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 100V
- Output Capacitance(Coss)
- 57pF
- Current - Continuous Drain(Id)
- 4A
- Ciss-Input Capacitance
- 859pF
- Pd - Power Dissipation
- 3.9W
- Reverse Transfer Capacitance (Crss)
- 33pF
- RDS(on)
- 125mΩ@10V;150mΩ@6V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 17nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.232 g
Overview
This next-generation trench MOSFET features a unique structure that combines low on-resistance with fast switching, making it ideal for high-efficiency power management applications.
Applications
- DC-DC converters
- Power management
- Disconnect switches
- Motor control
Key features
- Low on-resistance
- Fast switching speed
- Low gate drive
- SOT223 package
