MICROCHIP
24LC16BT-E/OT
16Kbit 400kHz I2C SOT-23-5 Memory RoHS
SOT-23-5ROHS3 CompliantActive
16K I²C Serial EEPROM
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,251 in stock
#C616242
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹129.85 | ₹129.85 |
| 10+ | ₹106.37 | ₹1,063.70 |
| 30+ | ₹93.31 | ₹2,799.30 |
| 100+ | ₹78.74 | ₹7,874.00 |
| 500+ | ₹72.22 | ₹36,110.00 |
| 1,000+ | ₹69.39 | ₹69,390.00 |
1 × ₹129.85
₹129.85
excl. GST
₹153.22 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
24LC16BT-E/OT
₹129.85 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+125℃
- Features
- Hardware write protection function;Noise suppression function
- Memory Size
- 16Kbit
- Voltage - Supply
- 2.5V~5.5V;3mA
- Clock Frequency
- 400kHz
- Access Time
- 900ns
- Data Retention - TDR (Year)
- 200 Years
- Write Cycle Time(tWC)
- 5ms
- Standby Supply Current
- 5uA
- Write Cycle Endurance
- 1,000,000 cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.044 g
Overview
The 24XX16 is a 16-Kbit Electrically Erasable PROM (EEPROM). The device is organized as eight blocks of 256x8-bit memory with a two-wire serial interface. Its low-voltage design permits operation down to 1.7V with standby and active currents of only 1μA and 1 mA, respectively. The 24XX16 also has a page write capability for up to 16 bytes of data.
Key features
- Single Supply with Operation down to 1.7V for 24AA16 and 24FC16 Devices, 2.5V for 24LC16B Devices
- Low-Power CMOS Technology:
- Read current 1 mA, maximum
- Standby current 1μA, maximum (I-Temp.)
- Two-Wire Serial Interface, I²C Compatible
- Schmitt Trigger Inputs for Noise Suppression
- Output Slope Control to Eliminate Ground Bounce
- 100 kHz, 400 kHz and 1 MHz Compatibility
- Page Write Time: 5 ms, Maximum
- Self-Timed Erase/Write Cycle
- 16-Byte Page Write Buffer
- Hardware Write-Protect
- ESD Protection > 4,000V
- More than 1 Million Erase/Write Cycles
- Data Retention > 200 Years
- Factory Programming Available
- RoHS Compliant
- Temperature Ranges:
- Industrial (I): -40℃ to +85℃
- Extended (E): -40℃ to +125℃
- Automotive AEC-Q100 Qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 24LC16BT-I/OT#C2061286MICROCHIP · SOT-23-5 | MICROCHIP | SOT-23-5 | 7,570 | ₹66.14 · 7,570 in stock | View |
| 24AA16T-E/OT#C616204MICROCHIP · SOT-23-5 | MICROCHIP | SOT-23-5 | 9 | ₹105.27 · 9 in stock | View | |
 | 24AA16T-I/OT#C122879MICROCHIP · SOT-23-5 | MICROCHIP | SOT-23-5 | 1,647 | ₹81.23 · 1,647 in stock | View |
 | 24AA16HT-I/OT#C2061344MICROCHIP · SOT-23-5 | MICROCHIP | SOT-23-5 | 8 | ₹70.62 · 8 in stock | View |
 | CAT24C16TDI-GT3#C605329onsemi · TSOT-23-5 | onsemi | TSOT-23-5 | 21 | ₹67.79 · 21 in stock | View |
