DIODESDatasheet (PDF)
74AHCT1G126W5-7
Schmitt trigger 4.5V~5.5V 1 1 4.7ns@5V,50pF SOT-25 Buffers, Drivers, Receivers, Transceivers RoHS
SOT-25ROHS3 CompliantActive
SINGLE BUFFER GATE WITH 3-STATE OUTPUT
- Manufacturer
- DIODES
- Manufacturer part #
- 74AHCT1G126W5-7
- Store part #
- C842288
- Package / case
- SOT-25
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,320 in stock
#C842288
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.14 | ₹91.40 |
| 100+ | ₹7.26 | ₹726.00 |
| 300+ | ₹6.32 | ₹1,896.00 |
| 3,000+ | ₹5.62 | ₹16,860.00 |
| 6,000+ | ₹5.05 | ₹30,300.00 |
| 9,000+ | ₹4.78 | ₹43,020.00 |
10 × ₹9.14
₹91.40
excl. GST
₹107.85 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AHCT1G126W5-7
₹91.40 for 10 + GST
Specifications
- Function
- Output enable
- Input type
- Schmitt trigger
- Current - Output High(IOH)
- 8mA
- Voltage - Supply
- 4.5V~5.5V
- Series
- 74AHCT
- Output Type
- Tri-State
- Current - Output Low(IOL)
- 8mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 1
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 40uA
- Propagation Delay
- 4.7ns@5V,50pF
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.064 g
Overview
The 74AHCT1G126 is a single non-inverting buffer/bus driver with a 3-state output. The output enters a high impedance state when a LOW-level is applied to the output enable (OE) pin. The device is designed for operation with a power supply range of 4.5V to 5.5V.
Applications
- General Purpose Logic
- PCs, networking, notebooks, netbooks, PDAs
- Computer peripherals, hard drives, CD/DVD ROM
- TV, DVD, DVR, set top box
- Phones, Personal Navigation / GPS
- MP3 players, Cameras, Video Recorders
Key features
- Supply Voltage Range from 4.5V to 5.5V
- ±8 mA Output Drive at 5.0V CMOS low power consumption
- Schmitt Trigger Action at All Inputs Make the Circuit Tolerant for Slower Input Rise and Fall Time
- ESD Protection per JESD 22: Exceeds 200-V Machine Model (A115-A); Exceeds 2000-V Human Body Model (A114-A); Exceeds 1000-V Charged Device Model (C101C)
- Latch-Up Exceeds 100mA per JESD 78, Class II
- SOT25 and SOT353: Assembled with “Green” Molding Compound (no Br, Sb) Lead Free Finish / RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN74AHCT1G126DBVR#C163712TI · SOT-23-5 | TI | SOT-23-5 | 8,180 | ₹12.98 · 8,180 in stock | View |
 | 74AHCT1G125QW5-7#C3755013DIODES · SOT-25 | DIODES | SOT-25 | 5 | ₹9.75 · 5 in stock | View |
 | 74AHCT1G125W5-7#C842287DIODES · SOT-25-5 | DIODES | SOT-25-5 | 2,050 | ₹16.26 · 2,050 in stock | View |
 | 74AHCT1G126GV,125#C554572Nexperia · SC-74A | Nexperia | SC-74A | 2,110 | ₹11.68 · 2,110 in stock | View |
 | 74AHCT1G125GV,125#C12494Nexperia · SOT-753 | Nexperia | SOT-753 | 415 | ₹45.10 · 415 in stock | View |
