ES83111.8V~3.3V 8kHz~96kHz QFN-20-EP(3x3) Signal Switches, Multiplexers, Decoders
From
₹74.18
1,00,212 in stock
NexperiaDatasheet (PDF)
74HC257D,653
8/4 2V~6V 160uA Tri-state output SOIC-16 Signal Switches, Multiplexers, Decoders RoHS
SOIC-16ROHS3 CompliantActive
Quad 2-input multiplexer; 3-state
- Manufacturer
- Nexperia
- Manufacturer part #
- 74HC257D,653
- Store part #
- C5627
- Package / case
- SOIC-16
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,198 in stock
#C5627
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹55.26 | ₹55.26 |
| 10+ | ₹43.08 | ₹430.80 |
| 30+ | ₹37.85 | ₹1,135.50 |
| 100+ | ₹31.55 | ₹3,155.00 |
| 500+ | ₹28.72 | ₹14,360.00 |
| 1,000+ | ₹26.98 | ₹26,980.00 |
1 × ₹55.26
₹55.26
excl. GST
₹65.21 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
74HC257D,653
₹55.26 for 1 + GST
Specifications
- Type
- Multiplexer
- Series
- 74HC
- Number of Channels
- 8/4
- Voltage - Supply
- 2V~6V
- Operating Temperature
- -40℃~+125℃
- Quiescent Current
- 160uA
- Current - Output High(IOH)
- 7.8mA
- Propagation Delay
- 19ns@6V;26ns@6V
- Function
- Tri-state output
- Current - Output Low(IOL)
- 7.8mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.275 g
Overview
The 74HC257; 74HCT257 is a quad 2-input multiplexer with 3-state outputs. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Applications
- System bus interface
- Logic level translation
- Data selection and multiplexing
- 3-state output control
Key features
- Wide supply voltage range from 2.0 V to 6.0 V
- CMOS low power dissipation
- High noise immunity
- Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
- Complies with JEDEC standards:
- JESD8C (2.7 V to 3.6 V)
- JESD7A (2.0 V to 6.0 V)
- Non-inverting data path
- 3-state outputs interface directly with system bus
- Input levels:
- For 74HC257: CMOS level
- For 74HCT257: TTL level
- ESD protection:
- HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V
- CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
- Specified from -40 °C to +85 °C and from -40 °C to +125 °C
