Nexperia

74LVC1G97GW,125

Schmitt trigger 32mA 4uA 32mA 1.65V~5.5V 1 TSSOP-6-1.3mm Gates and Inverters - Multi-Function, Configurable RoHS

TSSOP-6-1.3mmROHS3 CompliantActive

Low-power configurable multiple function gate

Manufacturer: Nexperia
Manufacturer part #: 74LVC1G97GW,125
Store part #: C548450
Package / case: TSSOP-6-1.3mm
Category: Gates and Inverters - Multi-Function, Configurable
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,300 in stock

#C548450

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
5+	₹19.25	₹96.25
50+	₹15.12	₹756.00
150+	₹13.04	₹1,956.00
500+	₹11.50	₹5,750.00
3,000+	₹10.27	₹30,810.00
6,000+	₹9.64	₹57,840.00

Quantity (min 5, multiples of 5)

5 × ₹19.25

₹96.25

excl. GST

₹113.57 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

74LVC1G97GW,125

₹96.25 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Logic Family: 74LVC
Input type: Schmitt trigger
Propagation Delay: 7.9ns@3V,50pF
Current - Output Low(IOL): 32mA
Output Logic Level - High: 2V
Quiescent Current(Iq): 4uA
Current - Output High(IOH): 32mA
Voltage - Supply: 1.65V~5.5V
Features: Local shutdown mode;Overvoltage-tolerant input
Operating Temperature: -40℃~+125℃
Number of Gates: 1
Output Logic Level - Low: 800mV

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.068 g

Overview

The 74LVC1G97 is a configurable multi-function gate circuit with Schmitt trigger inputs. This device can be configured to any of the following logic functions through a 3-bit input: MUX, AND gate, OR gate, NAND gate, NOR gate, inverter, and buffer. All inputs can be connected to VCC or GND. The inputs can be driven from 3.3 V or 5 V devices, allowing these devices to be used as level shifters in a mixed 3.3 V and 5 V environment. This device fully supports partial power-down applications using IOFF. The IOFF circuit disables the output to prevent damaging reverse current from flowing through the device when it is powered down.
