VBsemi ElecDatasheet (PDF)
BSC340N08NS3 G-VB
N-Channel 100V 30A 60W Surface Mount DFN5x6-8
DFN5x6-8RoHSActive
MOSFET N-CH 100V 30A DFN5x6-8
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- BSC340N08NS3 G-VB
- Store part #
- C7463900
- Package / case
- DFN5x6-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
41 in stock
#C7463900
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹209.43 | ₹209.43 |
| 10+ | ₹176.03 | ₹1,760.30 |
| 30+ | ₹157.75 | ₹4,732.50 |
| 100+ | ₹136.96 | ₹13,696.00 |
| 500+ | ₹116.79 | ₹58,395.00 |
| 1,000+ | ₹112.60 | ₹1,12,600.00 |
1 × ₹209.43
₹209.43
excl. GST
₹247.13 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
BSC340N08NS3 G-VB
₹209.43 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 100V
- Output Capacitance(Coss)
- 132pF
- Current - Continuous Drain(Id)
- 30A
- Ciss-Input Capacitance
- 1.47nF
- Pd - Power Dissipation
- 60W
- Reverse Transfer Capacitance (Crss)
- 11.2pF
- RDS(on)
- 17mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 20nC@10V
- Gate Threshold Voltage (Vgs(th))
- 5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.12 g
Overview
Applications
- Isolated DC/DC converter
- N-channel MOSFET
Key features
- Trench power MOSFET
- Junction temperature 175°C
- Low thermal resistance package
- 100% gate resistance (Rg) tested
- RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SI7454DP-T1-GE3-VB#C19188091VBsemi Elec · DFN5x6-8 | VBsemi Elec | DFN5x6-8 | 4 | ₹275.13 · 4 in stock | View |
 | BSC265N10LSF G-VB#C19188103VBsemi Elec · DFN5x6-8 | VBsemi Elec | DFN5x6-8 | 13 | ₹275.13 · 13 in stock | View |
 | SI7852DP-T1-GE3-VB#C19188108VBsemi Elec · DFN5x6-8 | VBsemi Elec | DFN5x6-8 | 35 | ₹232.50 · 35 in stock | View |
 | HM15N10D-VB#C19626726VBsemi Elec · DFN5x6-8 | VBsemi Elec | DFN5x6-8 | 20 | ₹247.31 · 20 in stock | View |
 | AON6452-VB#C20755124VBsemi Elec · DFN5x6-8 | VBsemi Elec | DFN5x6-8 | 10 | ₹201.03 · 10 in stock | View |
