BSZ010NE2LS5ATMA1-VB
20V 100A 250W 1 N-channel N-Channel DFN-8(3x3) Single FETs, MOSFETs
DFN-8(3x3)RoHSActive
MOSFET N-CH 20V 100A DFN-8(3x3)
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- BSZ010NE2LS5ATMA1-VB
- Store part #
- C51822624
- Package / case
- DFN-8(3x3)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
112 in stock
#C51822624
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹60.73 | ₹60.73 |
| 10+ | ₹48.12 | ₹481.20 |
| 30+ | ₹42.87 | ₹1,286.10 |
| 100+ | ₹36.14 | ₹3,614.00 |
| 500+ | ₹33.19 | ₹16,595.00 |
| 1,000+ | ₹31.32 | ₹31,320.00 |
1 × ₹60.73
₹60.73
excl. GST
₹71.66 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
BSZ010NE2LS5ATMA1-VB
₹60.73 for 1 + GST
Specifications
- Drain to Source Voltage
- 20V
- Operating Temperature
- -55℃~+175℃
- Current - Continuous Drain(Id)
- 100A
- Output Capacitance(Coss)
- 1.725nF
- Ciss-Input Capacitance
- 6.5nF
- Pd - Power Dissipation
- 250W
- Reverse Transfer Capacitance (Crss)
- 970pF
- RDS(on)
- 2mΩ@4.5V;2.5mΩ@2.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 171nC@10V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.07 g
Overview
Applications
- OR-ing diode
- Server
- DC/DC power supply
Key features
- Trench Power MOSFET
- 100% Rg and UIS tested
- RoHS compliant per EU Directive 2011/65/EU
