DMP4015SPS-13
N-Channel 40V 17A 2.1W Surface Mount TDSON-8-EP(5x6)
TDSON-8-EP(5x6)ROHS CompliantActive
MOSFET N-CH 40V 17A TDSON-8-EP(5x6)
- Manufacturer
- DIODES
- Manufacturer part #
- DMP4015SPS-13
- Store part #
- C155290
- Package / case
- TDSON-8-EP(5x6)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
183 in stock
#C155290
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹114.43 | ₹114.43 |
| 10+ | ₹96.08 | ₹960.80 |
| 30+ | ₹86.79 | ₹2,603.70 |
| 100+ | ₹77.73 | ₹7,773.00 |
| 500+ | ₹72.33 | ₹36,165.00 |
| 1,000+ | ₹69.52 | ₹69,520.00 |
1 × ₹114.43
₹114.43
excl. GST
₹135.03 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
DMP4015SPS-13
₹114.43 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 1.036nF
- Current - Continuous Drain(Id)
- 17A
- Ciss-Input Capacitance
- 4.234nF
- Pd - Power Dissipation
- 2.1W
- Reverse Transfer Capacitance (Crss)
- 526pF
- RDS(on)
- 15mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 47.5nC@5V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.2 g
Overview
This new generation MOSFET is designed to minimize the on-state resistance (RDS(ON)) yet maintain superior switching performance, making it ideal for high-efficiency power management applications.
Applications
- DC-DC converters
- Power management functions
- Analog switches
Key features
- 100% Unclamped Inductive Switch (UIS) Test In Production
- Low On-Resistance
- Fast Switching Speed
- Lead-Free Finish; RoHS Compliant
- Halogen and Antimony Free. “Green” Device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SP40P08NK#C41355190Siliup · PDFN-8L(5x6) | Siliup | PDFN-8L(5x6) | 60 | ₹37.51 · 60 in stock | View |
 | NVMFS5113PLT1G#C604582onsemi · SO-8FL | onsemi | SO-8FL | 45 | ₹291.18 · 45 in stock | View |
 | NVMFS5113PLWFT1G#C604583onsemi · SO-8FL | onsemi | SO-8FL | 38 | ₹403.24 · 38 in stock | View |
 | DON20P10#C48542679DOINGTER · DFN5x6-8 | DOINGTER | DFN5x6-8 | 2,000 | ₹23.73 · 2,000 in stock | View |
 | HSBA8119#C22359243HUASHUO · PRPAK5x6-8L | HUASHUO | PRPAK5x6-8L | 2,866 | ₹154.29 · 2,866 in stock | View |
