DMP510DLQ-7
50V 196mA 520mW 9.5Ω@5V 1 P-Channel SOT-23-3 Single FETs, MOSFETs RoHS
SOT-23-3ROHS3 CompliantActive
- Manufacturer
- DIODES
- Manufacturer part #
- DMP510DLQ-7
- Store part #
- C6540278
- Package / case
- SOT-23-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
100 in stock
#C6540278
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹31.25 | ₹31.25 |
| 10+ | ₹30.38 | ₹303.80 |
| 30+ | ₹29.95 | ₹898.50 |
| 100+ | ₹29.29 | ₹2,929.00 |
1 × ₹31.25
₹31.25
excl. GST
₹36.88 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMP510DLQ-7
₹31.25 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 50V
- Current - Continuous Drain(Id)
- 196mA
- Ciss-Input Capacitance
- 40pF
- Pd - Power Dissipation
- 520mW
- RDS(on)
- 9.5Ω@5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 500pC@10V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.058 g
Overview
This MOSFET is designed to meet the stringent requirements of automotive applications. It complies with the AEC-Q101 standard with Production Part Approval Process (PPAP) support, making it well-suited for the following applications: General-purpose interface switching Power management functions Analog switching
Applications
- General-purpose interface switch
- Power management function
- Analog switch
Key features
- Low on-resistance
- Low gate threshold voltage
- Low input capacitance
- Fast switching speed
- Low input/output leakage current
- Fully lead-free and fully RoHS compliant
- Halogen- and antimony-free, "Green" device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DMP610DLQ-7#C6601853DIODES · SOT-23-3 | DIODES | SOT-23-3 | 15 | ₹23.51 · 15 in stock | View |
 | FTZ30P35G#C3031432ARK micro · SOT-23 | ARK micro | SOT-23 | 4,844 | ₹196.89 · 4,844 in stock | View |
 | PJA3439#C2844879PANJIT · SOT-23 | PANJIT | SOT-23 | 1,295 | ₹9.82 · 1,295 in stock | View |
 | PJA3439-AU_R1_000A1#C5454403PANJIT · SOT-23 | PANJIT | SOT-23 | 3,935 | ₹15.24 · 3,935 in stock | View |
 | PJA3439_R1_00001#C7026693PANJIT · SOT-23 | PANJIT | SOT-23 | 1,500 | ₹10.91 · 1,500 in stock | View |
