DMP6350SQ-13
60V 1.5A 720mW 350mΩ@10V 1 P-Channel SOT-23-3 Single FETs, MOSFETs RoHS
SOT-23-3ROHS3 CompliantActive
- Manufacturer
- DIODES
- Manufacturer part #
- DMP6350SQ-13
- Store part #
- C6934893
- Package / case
- SOT-23-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
100 in stock
#C6934893
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹118.69 | ₹118.69 |
| 10+ | ₹94.38 | ₹943.80 |
| 30+ | ₹82.24 | ₹2,467.20 |
| 100+ | ₹70.30 | ₹7,030.00 |
| 500+ | ₹63.13 | ₹31,565.00 |
| 1,000+ | ₹59.46 | ₹59,460.00 |
1 × ₹118.69
₹118.69
excl. GST
₹140.05 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
DMP6350SQ-13
₹118.69 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 1.5A
- Ciss-Input Capacitance
- 206pF
- Pd - Power Dissipation
- 720mW
- Reverse Transfer Capacitance (Crss)
- 11pF
- RDS(on)
- 350mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 4.1nC@10V
- Gate Threshold Voltage (Vgs(th))
- 1.8V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.061 g
Overview
This MOSFET is designed to meet the stringent requirements of Automotive applications. It is qualified to AEC - Q101, supported by a PPAP and is ideal for use in: Backlighting, Power Management Functions, DC - DC Converters
Applications
- Backlighting
- Power Management Functions
- DC-DC Converters
Key features
- Low On-Resistance
- Low Input Capacitance
- Fast Switching Speed
- Low Input/Output Leakage
- Totally Lead-Free & Fully RoHS Compliant
- Halogen and Antimony Free. "Green" Device
- Qualified to AEC-Q101 Standards for High Reliability
- PPAP Capable
