MICROCHIPDatasheet (PDF)
DN3145N8-G
N-Channel 450V 100mA 1.3W Surface Mount SOT-89
SOT-89ROHS3 CompliantActive
MOSFET N-CH 450V 100mA SOT-89
- Manufacturer
- MICROCHIP
- Manufacturer part #
- DN3145N8-G
- Store part #
- C616347
- Package / case
- SOT-89
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
12 in stock
#C616347
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹243.54 | ₹243.54 |
| 10+ | ₹204.14 | ₹2,041.40 |
| 30+ | ₹179.58 | ₹5,387.40 |
| 100+ | ₹154.61 | ₹15,461.00 |
| 500+ | ₹143.20 | ₹71,600.00 |
| 1,000+ | ₹138.24 | ₹1,38,240.00 |
1 × ₹243.54
₹243.54
excl. GST
₹287.38 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
DN3145N8-G
₹243.54 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 450V
- Output Capacitance(Coss)
- 15pF
- Current - Continuous Drain(Id)
- 100mA
- Ciss-Input Capacitance
- 120pF
- Pd - Power Dissipation
- 1.3W
- Reverse Transfer Capacitance (Crss)
- 10pF
- RDS(on)
- 60Ω@0V
- Number
- 1 N-channel
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.262 g
Overview
The Supertex DN3145 is a depletion-mode (normally-on) transistor utilizing an advanced vertical DMOS structure and Supertex’s well-proven silicon-gate manufacturing process. This combination produces a device with the power handling capabilities of bipolar transistors and with the high input impedance and positive temperature coefficient inherent in MOS devices. Characteristic of all MOS structures, this device is free from thermal runaway and thermally-induced secondary breakdown. Supertex’s vertical DMOS FETs are ideally suited to a wide range of switching and amplifying applications where high breakdown voltage, high input impedance, low input capacitance, and fast switching speeds are desired.
Applications
- Normally-on switches
- Solid state relays
- Converters
- Constant current sources
- Power supply circuits
- Telecom
Key features
- High input impedance
- Low input capacitance
- Fast switching speeds
- Low on-resistance
- Free from secondary breakdown
- Low input and output leakage
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DMX5530E#C5354324ARK micro · SOT-89 | ARK micro | SOT-89 | 1,780 | ₹94.74 · 1,780 in stock | View |
 | FTX21N65G#C55968465ARK micro · SOT-89 | ARK micro | SOT-89 | 50 | ₹15.39 · 50 in stock | View |
 | DN3545N8-G#C556892MICROCHIP · SOT-89-3 | MICROCHIP | SOT-89-3 | 13 | ₹232.44 · 13 in stock | View |
 | DN2450N8-G#C616346MICROCHIP · SOT-89-3 | MICROCHIP | SOT-89-3 | 14 | ₹162.11 · 14 in stock | View |
 | VN2460N8-G#C145396MICROCHIP · SOT-89-3 | MICROCHIP | SOT-89-3 | On request | ₹409.47 · 0 in stock | View |
