SlkorDatasheet (PDF)
DW01
Battery Protection IC Lithium-ion/Polymer SOT-23-6
SOT-23-6ROHS3 CompliantActive
Lithium battery protection circuit
- Manufacturer
- Slkor
- Manufacturer part #
- DW01
- Store part #
- C359989
- Package / case
- SOT-23-6
- Category
- Battery Management
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10,720 in stock
#C359989
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.35 | ₹67.00 |
| 200+ | ₹2.59 | ₹518.00 |
| 600+ | ₹2.17 | ₹1,302.00 |
| 2,000+ | ₹1.92 | ₹3,840.00 |
| 10,000+ | ₹1.64 | ₹16,400.00 |
| 20,000+ | ₹1.52 | ₹30,400.00 |
20 × ₹3.35
₹67.00
excl. GST
₹79.06 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
DW01
₹67.00 for 20 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Quiescent Current
- 4uA
- 0V Battery Charge
- Support
- Operating Voltage
- 1.5V~10V
- Type of Battery
- Lithium Battery
- Features
- Overcharge protection;Over-discharge protection;Overcurrent Protection;Short-Circuit Protection
- The Chip Type
- Protection IC
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.035 g
Overview
DW01 is a lithium battery protection IC designed to prevent battery damage or shortened battery life caused by overcharge, over-discharge, and overcurrent conditions. It features high-accuracy voltage detection with time-delay circuitry, 0V charge enable, and auto-recovery functionality.
Applications
- Single lithium battery protection circuit.
Key features
- Low operating current
- Overcharge detection 4.28V, overcharge release 4.08V
- Over-discharge detection 2.4V, over-discharge release 3.0V
- Overcurrent detection 0.15V, short-circuit current detection 1.3V
- Charger detection
- Overcurrent protection reset resistor
- Auto-recovery function
- 0V charge enable
- Wide operating voltage range
- Compact package
