E-L9826TR
8 Active Low 1A Low Side Switch SOIC-20-300mil Power Distribution Switches, Load Drivers RoHS
SOIC-20-300milROHS3 CompliantActive
Octal protected low-side driver with diagnostic and serial/parallel input control
- Manufacturer
- ST
- Manufacturer part #
- E-L9826TR
- Store part #
- C155567
- Package / case
- SOIC-20-300mil
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
971 in stock
#C155567
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹317.37 | ₹317.37 |
| 10+ | ₹268.21 | ₹2,682.10 |
| 30+ | ₹237.54 | ₹7,126.20 |
| 100+ | ₹206.00 | ₹20,600.00 |
| 500+ | ₹191.65 | ₹95,825.00 |
| 1,000+ | ₹185.55 | ₹1,85,550.00 |
1 × ₹317.37
₹317.37
excl. GST
₹374.50 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
E-L9826TR
₹317.37 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+150℃
- Features
- Overcurrent Protection;Short-Circuit Protection;Over temperature protection;Overvoltage protection;Under-voltage lockout
- number of channels
- 8
- Control Input Logic
- Active Low
- Maximum Continuous Current
- 1A
- Operating Voltage
- 4.5V~5.5V
- RDS(on)
- 1.5Ω
- Type
- Low Side Switch
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 9.44 g
Overview
The L9826 is a protected octal low-side driver IC designed for the automotive environment. The 8 -bit serial peripheral interface (SPl) is able to control the device's eight channels and to provide its load's diagnosis. In addition output 1 and 2 can also be controlled through dedicated input pins NON1 and NON2. Overcurrent and short-circuit protections are present as well as the output voltage clamping which is able to protect the L9826 during operation with inductive loads.
Key features
- 8 channels low side driver with 450 mA output current capability
- Typical RDSON 1.5 Ω at TJ = 25 °C
- Parallel control for output 1 and 2
- SPI control on all outputs
- Reset function
- Diagnostic through 8 bit SPI
- Intrinsic output voltage clamping 50 V (Typ) protection for inductive load drive
- Short circuit current limitation and thermal shutdown for outputs 1 and 2
- Overcurrent and short circuit shutdown for outputs 3 to 8
