FDC654P
P-Channel 30V 3.6A 1.6W Surface Mount SuperSOT-6
SuperSOT-6ROHS3 CompliantActive
MOSFET P-CH 30V 3.6A SuperSOT-6
- Manufacturer
- onsemi
- Manufacturer part #
- FDC654P
- Store part #
- C81608
- Package / case
- SuperSOT-6
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
40 in stock
#C81608
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹101.26 | ₹101.26 |
| 10+ | ₹99.74 | ₹997.40 |
| 30+ | ₹98.66 | ₹2,959.80 |
| 100+ | ₹97.57 | ₹9,757.00 |
1 × ₹101.26
₹101.26
excl. GST
₹119.49 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
FDC654P
₹101.26 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 83pF
- Ciss-Input Capacitance
- 298pF
- Pd - Power Dissipation
- 1.6W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 3.6A
- Reverse Transfer Capacitance (Crss)
- 39pF
- RDS(on)
- 75mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 6.2nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 1.9V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.041 g
Overview
This P-Channel Logic Level MOSFET is produced using advanced PowerTrench process. It has been optimized for battery power management applications.
Applications
- Battery management
- Load switch
- Battery protection
Key features
- –3.6 A, –30 V. RDS(ON)=75 mΩ @ VGS=-10 V, RDS(ON)=125 mΩ @ ΔVGS=-4.5 V
- Low gate charge (6.2 nC typical)
- High performance trench technology for extremely low RDS(ON)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SP3407TS#C41354971Siliup · SOT-23-6L | Siliup | SOT-23-6L | 2,740 | ₹3.98 · 2,740 in stock | View |
 | SQ3427EV-T1_GE3#C727474VISHAY · TSOP-6 | VISHAY | TSOP-6 | 200 | ₹78.57 · 200 in stock | View |
 | DMP3050LVT-7#C397951DIODES · TSOT-26 | DIODES | TSOT-26 | 2,305 | ₹27.43 · 2,305 in stock | View |
 | FDC658AP#C3280198onsemi · SuperSOT-6 | onsemi | SuperSOT-6 | 1,455 | ₹60.90 · 1,455 in stock | View |
 | DMP3056LDM-7#C156392DIODES · SOT-26 | DIODES | SOT-26 | 3,040 | ₹28.50 · 3,040 in stock | View |
