GOSEMICONDatasheet (PDF)
GBI7256NMCR
4.5V~20V 5A 5A WSON-8-EP(3x3) Gate Drivers
WSON-8-EP(3x3)RoHSActive
Dual Channel High Speed Low Side Driver with Negative Input Capability
- Manufacturer
- GOSEMICON
- Manufacturer part #
- GBI7256NMCR
- Store part #
- C5451742
- Package / case
- WSON-8-EP(3x3)
- Category
- Gate Drivers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,483 in stock
#C5451742
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹43.25 | ₹43.25 |
| 10+ | ₹34.44 | ₹344.40 |
| 30+ | ₹30.65 | ₹919.50 |
| 100+ | ₹25.94 | ₹2,594.00 |
| 500+ | ₹21.64 | ₹10,820.00 |
| 1,000+ | ₹20.39 | ₹20,390.00 |
1 × ₹43.25
₹43.25
excl. GST
₹51.04 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
GBI7256NMCR
₹43.25 for 1 + GST
Specifications
- Low Level Delay Time
- 13ns
- High Level Delay Time
- 13ns
- Quiescent Current
- 65uA
- Voltage - Supply
- 4.5V~20V
- Driven Configuration
- Low Side
- Operating Temperature
- -40℃~+150℃
- Current - Output Low(IOL)
- 5A
- Rise Time
- 8.5ns
- Fall Time
- 6.5ns
- Features
- Enable shutdown;Interleaved conduction protection
- Current - Output High(IOH)
- 5A
- Load Type
- MOSFET;IGBT
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.04 g
Overview
Applications
- Power MOSFET gate drive
- IGBT gate drive
- Switching power supply
- Motor control
- Solar power
