IPB80N04S2-H4-VB
N-Channel 40V 100A 150W Surface Mount TO-263(D2PAK)
TO-263(D2PAK)RoHSActive
MOSFET N-CH 40V 100A TO-263(D2PAK)
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- IPB80N04S2-H4-VB
- Store part #
- C7494458
- Package / case
- TO-263(D2PAK)
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
49 in stock
#C7494458
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹118.65 | ₹118.65 |
| 10+ | ₹97.80 | ₹978.00 |
| 50+ | ₹75.41 | ₹3,770.50 |
| 100+ | ₹65.20 | ₹6,520.00 |
| 500+ | ₹58.90 | ₹29,450.00 |
| 1,000+ | ₹55.86 | ₹55,860.00 |
1 × ₹118.65
₹118.65
excl. GST
₹140.01 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
IPB80N04S2-H4-VB
₹118.65 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 1.395nF
- Current - Continuous Drain(Id)
- 100A
- Ciss-Input Capacitance
- 3.33nF
- Pd - Power Dissipation
- 150W
- Reverse Transfer Capacitance (Crss)
- 95pF
- RDS(on)
- 5mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 53nC@10V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.204 g
Overview
Applications
- Load Switch
Key features
- Thunder Power MOSFET
- Maximum junction temperature 175 °C
- 100% Rg and UIS tested
- Material category: RoHS compliant, halogen-free; see compliance definitions
- N-channel MOSFET
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | STB200NF04-VB#C20755246VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 20 | ₹107.14 · 20 in stock | View |
 | STB170NF04-VB#C2680799VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 40 | ₹100.60 · 40 in stock | View |
 | BUK7604-40A-VB#C29778933VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 10 | ₹102.93 · 10 in stock | View |
 | PSMN8R0-40BS,118-VB#C52190997VBsemi Elec · TO-263 | VBsemi Elec | TO-263 | 5 | ₹118.65 · 5 in stock | View |
 | PSMN4R5-40BS,118-VB#C52190998VBsemi Elec · TO-263 | VBsemi Elec | TO-263 | 5 | ₹118.65 · 5 in stock | View |
