IRF7904TRPBF-VB
4.16W 30V 9mΩ@10V 2 N-Channel N-Channel SO-8 Single FETs, MOSFETs
SO-8RoHSActive
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- IRF7904TRPBF-VB
- Store part #
- C52110043
- Package / case
- SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C52110043
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹82.73 | ₹82.73 |
| 10+ | ₹66.63 | ₹666.30 |
| 30+ | ₹59.65 | ₹1,789.50 |
| 100+ | ₹51.16 | ₹5,116.00 |
| 500+ | ₹42.46 | ₹21,230.00 |
| 1,000+ | ₹40.06 | ₹40,060.00 |
1 × ₹82.73
₹82.73
excl. GST
₹97.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
IRF7904TRPBF-VB
₹82.73 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 360pF
- Ciss-Input Capacitance
- 2.29nF
- Pd - Power Dissipation
- 4.16W
- Drain to Source Voltage
- 30V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 8A;15A
- Reverse Transfer Capacitance (Crss)
- 117pF
- RDS(on)
- 9mΩ@10V
- Number
- 2 N-Channel
- Gate Charge(Qg)
- 12.5nC
- Vgs
- ±16V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.45 g
Overview
Applications
- Notebook logic DC-DC conversion - Low current DC-DC conversion
Key features
- Halogen-free per IEC 61249-2-21
- Trench power MOSFET
- 100% Rg and UIS tested
- RoHS compliant per directive 2002/95/EC
- RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | VBA3316G#C516886VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 10 | ₹75.62 · 10 in stock | View |
 | SI4618DY-T1-E3-VB#C22388966VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 15 | ₹72.47 · 15 in stock | View |
 | SI4816BDY-T1-GE3-VB#C41413775VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 35 | ₹76.88 · 35 in stock | View |
| VBA3303#C42412408VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | On request | ₹101.22 · 0 in stock | View | |
