VISHAYDatasheet (PDF)
IRFL210TRPBF
N-Channel 200V 0.96A 2W Surface Mount SOT-223
SOT-223ROHS3 CompliantActive
MOSFET N-CH 200V 0.96A SOT-223
- Manufacturer
- VISHAY
- Manufacturer part #
- IRFL210TRPBF
- Store part #
- C3289914
- Package / case
- SOT-223
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,990 in stock
#C3289914
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹35.31 | ₹176.55 |
| 50+ | ₹30.77 | ₹1,538.50 |
| 150+ | ₹28.83 | ₹4,324.50 |
| 500+ | ₹25.11 | ₹12,555.00 |
| 2,500+ | ₹24.03 | ₹60,075.00 |
| 5,000+ | ₹23.38 | ₹1,16,900.00 |
5 × ₹35.31
₹176.55
excl. GST
₹208.33 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
IRFL210TRPBF
₹176.55 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 200V
- Output Capacitance(Coss)
- 53pF
- Current - Continuous Drain(Id)
- 960mA
- Ciss-Input Capacitance
- 140pF
- Pd - Power Dissipation
- 2W
- Reverse Transfer Capacitance (Crss)
- 15pF
- RDS(on)
- 1.5Ω@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 8.2nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.3 g
Overview
Third generation power MOSFETs provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The SOT-223 package is designed for surface-mounting using vapor phase, infrared, or wave soldering techniques. Its unique package design allows for easy automatic pick-and-place as with other SOT or SOIC packages but has the added advantage of improved thermal performance due to an enlarged tab for heatsinking. Power dissipation of greater than 1.25 W is possible in a typical surface mount application.
Key features
- Surface-mount
- Available in tape and reel RoHS
- Dynamic dV/dt rating COMPLIANT
- Repetitive avalanche rated HALOGEN
- Fast switching FREE
- Ease of paralleling Available
- Simple drive requirements
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IRFL210TRPBF#C469333VISHAY · SOT-223 | VISHAY | SOT-223 | 442 | ₹71.28 · 442 in stock | View |
 | VBJ1201K#C416323VBsemi Elec · SOT-223 | VBsemi Elec | SOT-223 | 39 | ₹68.56 · 39 in stock | View |
 | IRFL210TRPBF-TP#C41348194TECH PUBLIC · SOT-223 | TECH PUBLIC | SOT-223 | 4,630 | ₹27.10 · 4,630 in stock | View |
 | HSL03N20#C700961HUASHUO · SOT-223 | HUASHUO | SOT-223 | 1,760 | ₹46.75 · 1,760 in stock | View |
 | TPM2001NY3#C7603339TECH PUBLIC · SOT-223 | TECH PUBLIC | SOT-223 | 215 | ₹18.05 · 215 in stock | View |
