ST
M24C32-FMN6TP
32Kbit 1.7V~5.5V 1MHz I2C SO-8 Memory RoHS
SO-8ROHS3 CompliantActive
32-Kbit serial I2C bus EEPROM
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,235 in stock
#C2061453
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹34.23 | ₹171.15 |
| 50+ | ₹26.91 | ₹1,345.50 |
| 150+ | ₹23.77 | ₹3,565.50 |
| 500+ | ₹19.86 | ₹9,930.00 |
| 2,500+ | ₹18.11 | ₹45,275.00 |
| 5,000+ | ₹17.07 | ₹85,350.00 |
5 × ₹34.23
₹171.15
excl. GST
₹201.96 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
M24C32-FMN6TP
₹171.15 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Built-in power-on reset (POR);Built-in error correction code (ECC) function
- Memory Size
- 32Kbit
- Voltage - Supply
- 1.7V~5.5V
- Clock Frequency
- 1MHz
- Data Retention - TDR (Year)
- 200 Years
- Write Cycle Time(tWC)
- 5ms
- Write Cycle Endurance
- 4,000,000 Cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.284 g
Overview
This is an EEPROM device with I²C interface, available in multiple package options including PDIP8 (BN), TSSOP8 (DW, 169 mil wide), SO8 (MN, 150 mil wide), UFDFPN8 (MC, DFN8-2×3 mm), UFDFPN5 (MH, DFN5-1.7×1.4 mm), WLCSP (CU), and uncut wafer.
Key features
- Compatible with all I²C bus modes: 1 MHz, 400 kHz, 100 kHz
- Memory array: 32 Kbit (4 Kbyte) of EEPROM
- Page size: 32 byte
- Additional Write lockable page (M24C32-D order codes)
- Single supply voltage: 1.7V to 5.5 V over -40℃ / +85℃, 1.6V to 5.5V over -20℃ / +85℃
- Write: Byte Write within 5 ms, Page Write within 5 ms
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | M24C32-DFMN6TP#C2061187ST · SOP-8 | ST | SOP-8 | 182 | ₹60.33 · 182 in stock | View |
 | 24CW320T-I/SN#C2061389MICROCHIP · SOIC-8 | MICROCHIP | SOIC-8 | 3 | ₹76.51 · 3 in stock | View |
 | P24C32C-SSH-MIR#C2977254PUYA · SOP-8 | PUYA | SOP-8 | 3,930 | ₹15.84 · 3,930 in stock | View |
 | HG24LC32M/TR#C3007882HGSEMI · SOP-8 | HGSEMI | SOP-8 | 2,295 | ₹22.68 · 2,295 in stock | View |
 | FM24C32D-SO-T-G#C461627FUDAN MICRO · SOIC-8 | FUDAN MICRO | SOIC-8 | 2,385 | ₹27.39 · 2,385 in stock | View |
