MK10DN32VLF5

K10 sub-series products support the following specific part numbers: MK10DN32VFM5, MK10DX32VFM5, MK10DN64VFM5, MK10DX64VFM5, MK10DN128VFM5, MK10DX128VFM5. Valid orderable part numbers are available on the website. To identify orderable part numbers for this device, search using the following device numbers: PK10, MK10. The IC part number contains fields that identify the specific part; the exact part received can be determined by the values of these fields.

Key features

• Operating voltage range: 1.71 V to 3.6 V
• Flash write voltage range: 1.71 V to 3.6 V
• Ambient operating temperature range: -40 ℃ to 105 ℃
• Up to 50 MHz ARM Cortex-M4 core with DSP instructions, delivering 1.25 Dhrystone MIPS performance per MHz
• Up to 128 KB program flash
• FlexMemory devices with up to 32 KB FlexNVM
• FlexMemory devices with 2 KB FlexRAM
• Up to 16 KB RAM
• Serial programming interface (EzPort)
• 3 to 32 MHz crystal oscillator support
• 32 kHz crystal oscillator support
• Multipurpose clock generator
• Multiple low-power modes for application-specific power optimization
• 4-channel DMA controller supporting up to 41 request sources
• External watchdog monitor
• Software watchdog
• Low-leakage wakeup unit
• Hardware CRC module for fast cyclic redundancy check
• 128-bit unique identification code (ID) per device
• Integrated 16-bit SAR ADC
• Two integrated analog comparators (CMP) with 6-bit DAC and programmable reference input
• Programmable delay block
• 8-channel motor control/general-purpose/PWM timer
• 2-channel quadrature decode/general-purpose timer
• Periodic interrupt timer
• 16-bit low-power timer
• Carrier modulator transmitter
• Real-time clock
• Integrated SPI module
• Integrated I2C module
• Three integrated UART modules
• Integrated I2S module
