NL7SZ57DFT2G
Schmitt trigger 1.65V~5.5V 32mA 1uA 32mA 1 SOT-363 Gates and Inverters - Multi-Function, Configurable RoHS
SOT-363ROHS3 CompliantActive
Configurable Multifunction Gate
- Manufacturer
- onsemi
- Manufacturer part #
- NL7SZ57DFT2G
- Store part #
- C94398
- Package / case
- SOT-363
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,270 in stock
#C94398
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.57 | ₹85.70 |
| 100+ | ₹6.76 | ₹676.00 |
| 300+ | ₹5.86 | ₹1,758.00 |
| 3,000+ | ₹5.19 | ₹15,570.00 |
| 6,000+ | ₹4.63 | ₹27,780.00 |
| 9,000+ | ₹4.37 | ₹39,330.00 |
10 × ₹8.57
₹85.70
excl. GST
₹101.13 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NL7SZ57DFT2G
₹85.70 for 10 + GST
Specifications
- Logic Family
- 7SZ Series
- Input type
- Schmitt trigger
- Propagation Delay
- 5.1ns@5V,50pF
- Voltage - Supply
- 1.65V~5.5V
- Operating Temperature
- -55℃~+125℃
- Output Logic Level - Low
- 450mV;300mV;400mV;550mV
- Current - Output Low(IOL)
- 32mA
- Output Logic Level - High
- 1.2V;1.9V;2.4V;3.8V
- Quiescent Current(Iq)
- 1uA
- Current - Output High(IOH)
- 32mA
- Features
- Overvoltage-tolerant input;Local shutdown mode
- Number of Gates
- 1
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.027 g
Overview
The NL7SZ57 is an advanced high−speed CMOS multifunction gate. The device allows the user to choose logic functions AND, OR, NAND, NOR, XNOR, INVERT and BUFFER. The device has Schmitt−trigger inputs, thereby enhancing noise immunity. The NL7SZ57 input and output structures provide protection when voltages up to 7.0 V are applied, irregardless of the supply voltage.
Key features
- High Speed: tpD = 3.2 ns (Typ) @ VCC = 5.0 V
- Low Power Dissipation: ICC = 1 μA (Maximum) at TA = 25℃
- Power Down Protection Provided on inputs
- Balanced Propagation Delays
- Overvoltage Tolerant (OVT) Input and Output Pins
- Ultra−Small Package
- This is a Pb−Free Device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 74LVC1G97DW-7#C460532DIODES · SOT-363 | DIODES | SOT-363 | 4,510 | ₹30.19 · 4,510 in stock | View |
 | 74LVC1G58DW-7#C842512DIODES · SOT-363-6 | DIODES | SOT-363-6 | 120 | ₹9.78 · 120 in stock | View |
| SN74LVC1G97IDCKREP#C2867306TI · SC-70-6 | TI | SC-70-6 | 6 | ₹407.83 · 6 in stock | View | |
 | SN74LVC1G97DCK3#C2861177TI · SC-70-6 | TI | SC-70-6 | 265 | ₹45.43 · 265 in stock | View |
 | 74LVC1G98GW,125#C548458Nexperia · TSSOP-6 | Nexperia | TSSOP-6 | 1,435 | ₹31.04 · 1,435 in stock | View |
