NSL2020B
Battery Charging IC Lithium Battery SOT-23-6
SOT-23-6ROHS CompliantActive
Pneumatic control chip integrated with microphone sensor
- Manufacturer
- WXNSIC
- Manufacturer part #
- NSL2020B
- Store part #
- C49021832
- Package / case
- SOT-23-6
- Category
- Battery Management
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,440 in stock
#C49021832
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.71 | ₹63.55 |
| 50+ | ₹9.96 | ₹498.00 |
| 150+ | ₹8.59 | ₹1,288.50 |
| 500+ | ₹7.55 | ₹3,775.00 |
| 3,000+ | ₹6.73 | ₹20,190.00 |
| 6,000+ | ₹6.31 | ₹37,860.00 |
5 × ₹12.71
₹63.55
excl. GST
₹74.99 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NSL2020B
₹63.55 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Quiescent Current
- 2.5uA
- 0V Battery Charge
- Not supported
- Type of Battery
- Lithium Battery
- Features
- Trickle charging;Constant current charging;Constant voltage charging;Short-Circuit Protection;Under-voltage lockout;Overcurrent Protection
- The Chip Type
- Charging IC
- Charge Current - Max
- 650mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.055 g
Overview
Key features
- Microphone direct input supported
- Integrated Li-ion battery trickle, constant current, and constant voltage charging management
- Constant current charging: 650mA
- Full charge voltage: 4.2V, accuracy ±50mV
- Integrated 4A discharge MOS switch
- Only 5μA battery consumption when charging input is absent
- Integrated short circuit protection (SCP)
- Integrated under-voltage lockout (UVLO)
- Integrated over-temperature protection (OTP)
- Integrated fast-response discharge over-current protection (OCP)
- Rich LED status indication
- ASIC design
- SOT23-6 package
