NTE4153NT1G
20V 915mA 127mΩ@4.5V 1 N-channel SC-89 Single FETs, MOSFETs RoHS
SC-89ROHS3 CompliantActive
MOSFET N-CH 20V 915mA SC-89
- Manufacturer
- onsemi
- Manufacturer part #
- NTE4153NT1G
- Store part #
- C79836
- Package / case
- SC-89
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,010 in stock
#C79836
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹19.05 | ₹95.25 |
| 50+ | ₹15.52 | ₹776.00 |
| 150+ | ₹13.76 | ₹2,064.00 |
| 500+ | ₹11.15 | ₹5,575.00 |
| 3,000+ | ₹10.09 | ₹30,270.00 |
| 6,000+ | ₹9.57 | ₹57,420.00 |
5 × ₹19.05
₹95.25
excl. GST
₹112.40 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NTE4153NT1G
₹95.25 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 915mA
- Ciss-Input Capacitance
- 110pF
- Reverse Transfer Capacitance (Crss)
- 12pF
- RDS(on)
- 127mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 1.82nC
- Gate Threshold Voltage (Vgs(th))
- 450mV
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.033 g
Overview
Applications
- Load/power switches
- Power conversion circuits
- Battery management
- Portable devices such as mobile phones, PDAs, digital cameras, pagers, etc.
Key features
- Low on-resistance (RDS(on)) for improved system efficiency
- Low threshold voltage, rated at 1.5 V
- ESD protection on gate
- NV prefix for automotive and other applications requiring specific country of origin and change control requirements; AEC-Q101 compliant with PPAP documentation available
- Lead-free package available
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TPNTA4153NT1G#C2875154TECH PUBLIC · SOT-523 | TECH PUBLIC | SOT-523 | 7,310 | ₹5.61 · 7,310 in stock | View |
 | VBTA1220N#C416339VBsemi Elec · SC-75-3 | VBsemi Elec | SC-75-3 | 295 | ₹10.62 · 295 in stock | View |
 | HSST2302#C54842085HUASHUO · SOT-523 | HUASHUO | SOT-523 | 100 | ₹5.28 · 100 in stock | View |
 | NVA4153NT1G#C5208928onsemi · SC-75-3 | onsemi | SC-75-3 | 38 | ₹197.10 · 38 in stock | View |
 | NVE4153NT1G#C604543onsemi · SC-89 | onsemi | SC-89 | 2 | ₹182.92 · 2 in stock | View |
