onsemiDatasheet (PDF)
NTHL060N090SC1
900V 46A 221W 84mΩ 1 N-channel N-Channel TO-247-3 Single FETs, MOSFETs RoHS
TO-247-3ROHS3 CompliantActive
SiC Power N-channel MOSFET
- Manufacturer
- onsemi
- Manufacturer part #
- NTHL060N090SC1
- Store part #
- C898279
- Package / case
- TO-247-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15 in stock
#C898279
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,725.59 | ₹1,725.59 |
| 10+ | ₹1,494.83 | ₹14,948.30 |
| 30+ | ₹1,353.98 | ₹40,619.40 |
| 90+ | ₹1,235.91 | ₹1,11,231.90 |
1 × ₹1,725.59
₹1,725.59
excl. GST
₹2,036.20 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 30 per tube
NTHL060N090SC1
₹1,725.59 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 900V
- Output Capacitance(Coss)
- 113pF
- Current - Continuous Drain(Id)
- 46A
- Ciss-Input Capacitance
- 1.77nF
- Pd - Power Dissipation
- 221W
- Reverse Transfer Capacitance (Crss)
- 11pF
- RDS(on)
- 84mΩ
- Number
- 1 N-channel
- Gate Charge(Qg)
- 87nC
- Gate Threshold Voltage (Vgs(th))
- 4.3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 30 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 8.86 g
Overview
Applications
- UPS DC/DC Converter
- Boost Inverter
Key features
- Typ. RDS(on)=60 mΩ
- Ultra Low Gate Charge (typ. QG(tot)=87 nC)
- Low Effective Output Capacitance (typ. Coss=113 pF)
- 100% UIL Tested
- These Devices are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IMW120R030M1H#C536280Infineon · TO-247-3 | Infineon | TO-247-3 | On request | ₹1,683.87 · 0 in stock | View |
 | NTHL040N120M3S#C20625009onsemi · TO-247-3L | onsemi | TO-247-3L | 8 | ₹1,597.34 · 8 in stock | View |
 | NTHL040N120SC1#C898278onsemi · TO-247-3 | onsemi | TO-247-3 | 1 | ₹3,007.63 · 1 in stock | View |
| IMW120R040M1HXKSA1#C6061982Infineon · TO-247-3 | Infineon | TO-247-3 | 30 | ₹1,855.72 · 30 in stock | View | |
 | AIMW120R035M1HXKSA1#C3289085Infineon · TO-247-3-41 | Infineon | TO-247-3-41 | 5 | ₹5,481.04 · 5 in stock | View |
