NTMS4816NR2G
N-Channel 30V 9A 1.37W Surface Mount SO-8
SO-8ROHS3 CompliantDiscontinued
MOSFET N-CH 30V 9A SO-8
- Manufacturer
- onsemi
- Manufacturer part #
- NTMS4816NR2G
- Store part #
- C179627
- Package / case
- SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
17 in stock
#C179627
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹122.59 | ₹122.59 |
| 10+ | ₹98.37 | ₹983.70 |
| 30+ | ₹86.15 | ₹2,584.50 |
| 100+ | ₹74.14 | ₹7,414.00 |
| 500+ | ₹66.89 | ₹33,445.00 |
| 1,000+ | ₹63.16 | ₹63,160.00 |
1 × ₹122.59
₹122.59
excl. GST
₹144.66 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
NTMS4816NR2G
₹122.59 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 220pF
- Ciss-Input Capacitance
- 1.06nF
- Pd - Power Dissipation
- 1.37W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 9A
- Reverse Transfer Capacitance (Crss)
- 126pF
- RDS(on)
- 16mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 18.3nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Discontinued
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.216 g
Overview
Applications
- Disk Drives
- DC−DC Converters
- Printers
Key features
- Low RDS(on) to Minimize Conduction Losses
- Low Capacitance to Minimize Driver Losses
- Optimized Gate Charge to Minimize Switching Losses
- These Devices are Pb−Free and are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | AP3020#C353077ALLPOWER · SO-8 | ALLPOWER | SO-8 | 2,195 | ₹33.19 · 2,195 in stock | View |
 | SM4480PRL#C350659SPS · SOP-8 | SPS | SOP-8 | 5 | ₹30.50 · 5 in stock | View |
 | SI4124DY-T1-E3-VB#C19711180VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 9 | ₹72.47 · 9 in stock | View |
 | HY1106S#C176659HUAYI · SOP-8 | HUAYI | SOP-8 | 1 | ₹30.48 · 1 in stock | View |
 | SI4420BDY-T1-E3#C7010733VISHAY · SOIC-8 | VISHAY | SOIC-8 | 251 | ₹146.68 · 251 in stock | View |
