NVTFS5124PLTAG-VB
P-Channel 60V 5A Surface Mount DFN3x3-8
DFN3x3-8RoHSActive
MOSFET P-CH 60V 5A DFN3x3-8
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- NVTFS5124PLTAG-VB
- Store part #
- C47993765
- Package / case
- DFN3x3-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5 in stock
#C47993765
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹76.95 | ₹76.95 |
| 10+ | ₹61.04 | ₹610.40 |
| 30+ | ₹54.16 | ₹1,624.80 |
| 100+ | ₹45.56 | ₹4,556.00 |
| 500+ | ₹41.91 | ₹20,955.00 |
| 1,000+ | ₹39.54 | ₹39,540.00 |
1 × ₹76.95
₹76.95
excl. GST
₹90.80 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
NVTFS5124PLTAG-VB
₹76.95 for 1 + GST
Specifications
- Drain to Source Voltage
- 60V
- Operating Temperature
- -55℃~+150℃
- Output Capacitance(Coss)
- 130pF
- Current - Continuous Drain(Id)
- 5A
- Ciss-Input Capacitance
- 1nF
- Pd - Power Dissipation
- 38.5W
- Reverse Transfer Capacitance (Crss)
- 90pF
- RDS(on)
- 140mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 40nC
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.29 g
Overview
Applications
- High-side switches for full-bridge converters
- DC/DC converters for LCD displays
Key features
- Halogen-free per IEC 61249-2-21
- Trench power MOSFET
- 100% UIS tested
- RoHS compliant per directive 2002/95/EC
