NexperiaDatasheet (PDF)
PTVS28VP1UP,115
45.4VC Clamp 13.2A Ipp TVS DIODE SOD-128
SOD-128ROHS3 CompliantActive
TVS DIODE 28VWM 45.4VC SOD-128
- Manufacturer
- Nexperia
- Manufacturer part #
- PTVS28VP1UP,115
- Store part #
- C553404
- Package / case
- SOD-128
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
325 in stock
#C553404
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹30.39 | ₹151.95 |
| 50+ | ₹23.55 | ₹1,177.50 |
| 150+ | ₹20.63 | ₹3,094.50 |
| 500+ | ₹16.97 | ₹8,485.00 |
| 3,000+ | ₹15.35 | ₹46,050.00 |
| 6,000+ | ₹14.37 | ₹86,220.00 |
5 × ₹30.39
₹151.95
excl. GST
₹179.30 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PTVS28VP1UP,115
₹151.95 for 5 + GST
Specifications
- Clamping Voltage
- 45.4V
- Peak Pulse Current (Ipp)
- 13.2A
- Peak Pulse Power Dissipation (Ppp)
- 600W
- Number of Channels
- 1
- Voltage - Breakdown
- 31.1V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 100nA
- Reverse Stand-Off Voltage (Vrwm)
- 28V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.12 g
Overview
600 W unidirectional Transient Voltage Suppressor (TVS) in a SOD128 small and flat lead Surface-Mounted Device (SMD) plastic package, designed for transient overvoltage protection.
Applications
- Power supply protection
- Automotive application
- Industrial application
- Power management
Key features
- Rated peak pulse power: P_PPM = 600 W
- Very low package height: 1 mm
- Reverse standoff voltage range: V_RWM = 3.3 V to 64 V
- Reverse current: I_RM = 0.001 μA
- AEC - Q101 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PTVS26VP1UTP,115#C553401Nexperia · SOD-128 | Nexperia | SOD-128 | 99 | ₹119.24 · 99 in stock | View |
 | PTVS30VP1UTP,115#C553409Nexperia · SOD-128 | Nexperia | SOD-128 | 2 | ₹54.51 · 2 in stock | View |
| VS28VUA1LAMTR#C3702933ROHM · SOD-128 | ROHM | SOD-128 | On request | ₹24.32 · 0 in stock | View | |
| VS28VUA1LAMTFTR#C3712965ROHM · SOD-128 | ROHM | SOD-128 | On request | ₹26.59 · 0 in stock | View | |
| PTVS28VP1UP-QX#C20235911Nexperia · SOD-128 | Nexperia | SOD-128 | On request | ₹40.56 · 0 in stock | View | |
