SMAJ36CA-Q
75.5VC Clamp 34.5A@8/20us Ipp TVS DIODE SMA(DO-214AC)
TVS DIODE 36VWM 75.5VC SMA(DO-214AC)
- Manufacturer
- BOURNS
- Manufacturer part #
- SMAJ36CA-Q
- Store part #
- C1880491
- Package / case
- SMA(DO-214AC)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
85 in stock
#C1880491
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹99.04 | ₹99.04 |
| 10+ | ₹79.50 | ₹795.00 |
| 30+ | ₹69.95 | ₹2,098.50 |
| 100+ | ₹60.17 | ₹6,017.00 |
| 500+ | ₹54.52 | ₹27,260.00 |
| 1,000+ | ₹51.48 | ₹51,480.00 |
1 × ₹99.04
₹99.04
excl. GST
₹116.87 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
SMAJ36CA-Q
₹99.04 for 1 + GST
Specifications
- Clamping Voltage
- 75.5V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 34.5A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 400W
- Number of Channels
- 1
- Voltage - Breakdown
- 44.2V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 36V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.128 g
Overview
Bourns offers Transient Voltage Suppressor Diodes for surge and ESD protection applications, in compact chip package DO-214AC (SMA) size format. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 220 V. Typical fast response times are less than 1.0 picosecond from 0 V to Breakdown Voltage.
Applications
- Protection of power buses
- Protection of I/O interfaces
- Overvoltage transient protection
- Telecom, computer, industrial and consumer electronics applications
Key features
- Surface Mount SMA package
- Standoff Voltage: 5 to 220 volts
- Power Dissipation: 400 watts
- RoHS compliant
- AEC-Q101 compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TPSMAJ36CA#C41425660TECH PUBLIC · DO-214AC(SMA) | TECH PUBLIC | DO-214AC(SMA) | 4,430 | ₹7.58 · 4,430 in stock | View |
 | SMAJ33CA-TR#C132941ST · SMA(DO-214AC) | ST | SMA(DO-214AC) | 110 | ₹32.32 · 110 in stock | View |
 | SMAJ33CA-Q#C1973988BOURNS · SMA(DO-214AC) | BOURNS | SMA(DO-214AC) | On request | ₹25.71 · 0 in stock | View |
| SMAJ36CHR3G#C2443637Taiwan Semiconductor · SMA(DO-214AC) | Taiwan Semiconductor | SMA(DO-214AC) | On request | ₹17.11 · 0 in stock | View | |
| SMAJ36CH#C3699913Taiwan Semiconductor · DO-214AC(SMA) | Taiwan Semiconductor | DO-214AC(SMA) | On request | ₹19.42 · 0 in stock | View | |
