SN74HC138DTR(XBLW)
3/8 2V~6V 8uA 26ns@6V,50pF SOP-16 Signal Switches, Multiplexers, Decoders RoHS
SOP-16ROHS CompliantActive
3-to-8 Line Decoder/Demultiplexer; Inverting
- Manufacturer
- XBLW
- Manufacturer part #
- SN74HC138DTR(XBLW)
- Store part #
- C41361402
- Package / case
- SOP-16
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,800 in stock
#C41361402
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹14.51 | ₹72.55 |
| 50+ | ₹11.40 | ₹570.00 |
| 150+ | ₹9.86 | ₹1,479.00 |
| 500+ | ₹8.69 | ₹4,345.00 |
| 2,500+ | ₹7.75 | ₹19,375.00 |
| 5,000+ | ₹7.29 | ₹36,450.00 |
5 × ₹14.51
₹72.55
excl. GST
₹85.61 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SN74HC138DTR(XBLW)
₹72.55 for 5 + GST
Specifications
- Type
- Decoder
- Series
- 74HC
- Number of Channels
- 3/8
- Voltage - Supply
- 2V~6V
- Operating Temperature
- -40℃~+125℃
- Quiescent Current
- 8uA
- Current - Output High(IOH)
- 5.2mA
- Propagation Delay
- 26ns@6V,50pF
- Current - Output Low(IOL)
- 5.2mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.292 g
Overview
The SN74HC138 is a decodes three binary weighted address inputs (A0, A1 and A2) to eight mutually exclusive outputs (Y0 to Y7). The device features three enable inputs (E1, E2 and E3). Every output will be HIGH unless E1 and E2 are LOW and E3 is HIGH. This multiple enable function allows easy parallel expansion to a 1-of-32 (5 to 32 lines) decoder with just four SN74HC138 ICs and one inverter. The SN74HC138 can be used as an eight output demultiplexer by using one of the active LOW enable inputs as the data input and the remaining enable inputs as strobes. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Applications
- LED Displays
- Servers
- White Goods
- Power Infrastructure
- Building Automation
- Factory Automation
Key features
- Wide operating voltage range: 2 V to 6 V
- Demultiplexing capability
- Multiple input enable for easy expansion
- Ideal for memory chip select decoding
- Active LOW mutually exclusive outputs
- Specified from -40℃ to +125℃
