Silergy

SY6863B3ABC

3A Active High High Side Switch SOT-23-6 Power Distribution Switches, Load Drivers

SOT-23-6RoHSActive

Manufacturer: Silergy
Manufacturer part #: SY6863B3ABC
Store part #: C2687365
Package / case: SOT-23-6
Category: Power Distribution Switches, Load Drivers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,890 in stock

#C2687365

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
1+	₹67.66	₹67.66
10+	₹53.99	₹539.90
30+	₹48.14	₹1,444.20
100+	₹40.76	₹4,076.00
500+	₹37.52	₹18,760.00
1,000+	₹35.56	₹35,560.00

Quantity (min 1)

1 × ₹67.66

₹67.66

excl. GST

₹79.84 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

SY6863B3ABC

₹67.66 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+85℃
Features: Overcurrent Protection;Short-Circuit Protection;Over temperature protection;Overvoltage protection;Under-voltage lockout;Reverse current blocking
Maximum Continuous Current: 3A
Control Input Logic: Active High
RDS(on): 45mΩ
Operating Voltage: 2.5V~5.5V
Type: High Side Switch

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.051 g

Overview

This is a 3A low-loss power distribution switch with ultra-low on-resistance, featuring built-in current limiting to protect the power supply against overcurrent and short-circuit conditions. The device provides overvoltage protection, with its output pin capable of withstanding 28V. It integrates overtemperature protection and reverse blocking. Supporting USB PD3.0 Fast Role Swap, the output voltage can recover to the USB valid voltage range within 110μs during a USB PD Fast Role Swap event.
