MDD(Microdiode Semiconductor)Datasheet (PDF)
74AHC1G08GW
StandardCMOS 2V~5.5V 9.5ns@3.3V,15pF 10nA SOT-353 Gates and Inverters
SOT-353RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74AHC1G08GW
- Store part #
- C52140486
- Package / case
- SOT-353
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
11,777 in stock
#C52140486
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹7.65 | ₹7.65 |
| 10+ | ₹6.03 | ₹60.30 |
| 30+ | ₹5.21 | ₹156.30 |
| 100+ | ₹4.62 | ₹462.00 |
| 500+ | ₹4.13 | ₹2,065.00 |
| 1,000+ | ₹3.89 | ₹3,890.00 |
1 × ₹7.65
₹7.65
excl. GST
₹9.03 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AHC1G08GW
₹7.65 for 1 + GST
Specifications
- Input Type
- StandardCMOS
- Logic Family
- 74AHC Series
- Voltage - Supply
- 2V~5.5V
- Propagation Delay
- 9.5ns@3.3V,15pF
- Output Logic Level - Low
- 360mV~550mV;100mV
- Features
- Overvoltage-tolerant input
- Input Logic Level - Low
- 500mV~1.65V
- Input Logic Level - High
- 1.5V~3.85V
- Operating Temperature
- -40℃~+125℃
- Output Logic Level - High
- 4.4V~4.5V;3.7V~3.94V;2.9V~3V;1.9V~2V
- Quiescent Current(Iq)
- 10nA
- Number of Channels
- 1;2
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.074 g
Overview
74AHC1G08 and 74AHCT1G08 are single 2-input AND gates. Their inputs feature overvoltage tolerance, which allows these devices to be used as level translators in mixed-voltage environments.
Key features
- Wide supply voltage range: 2.0V ~ 5.5V
- Input overvoltage tolerance up to 5.5V
- High noise immunity
- CMOS low power consumption
- Latch-up performance exceeds 200mA
- Symmetrical output impedance
- Balanced propagation delay
- Input levels:
- 74AHC1G08: CMOS level
- 74AHCT1G08: TTL level
- ESD protection:
- HBM ANSI/ESDA/JEDEC JS-001 Class 3A, exceeds 7000V
- CDM ANSI/ESDA/JEDEC JS-002 Class C3, exceeds 2000V
- Multiple package options
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 74AHC1G09GW#C52140485MDD(Microdiode Semiconductor) · SOT-353 | MDD(Microdiode Semiconductor) | SOT-353 | 2,747 | ₹14.46 · 2,747 in stock | View |
