74LVC1G97GW
Schmitt trigger 1.65V~5.5V 5.5ns@4.5V,50pF 100nA SOT-363 Gates and Inverters
SOT-363RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74LVC1G97GW
- Store part #
- C52953355
- Package / case
- SOT-363
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,470 in stock
#C52953355
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹14.61 | ₹73.05 |
| 50+ | ₹11.51 | ₹575.50 |
| 150+ | ₹9.98 | ₹1,497.00 |
| 500+ | ₹8.81 | ₹4,405.00 |
| 3,000+ | ₹7.89 | ₹23,670.00 |
| 6,000+ | ₹7.42 | ₹44,520.00 |
5 × ₹14.61
₹73.05
excl. GST
₹86.20 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LVC1G97GW
₹73.05 for 5 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Family
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Propagation Delay
- 5.5ns@4.5V,50pF
- Operating Temperature
- -40℃~+125℃
- Features
- Local shutdown mode;Overvoltage-tolerant input
- Quiescent Current(Iq)
- 100nA
- Number of Channels
- 1;3
- Current - Output High(IOH)
- 32mA
- Current - Output Low(IOL)
- 32mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.073 g
Overview
The 74LVC1G97 is a configurable multi-function logic gate with Schmitt-trigger inputs. The device can be configured via 3-bit inputs to implement any of the following logic functions: multiplexer, AND, OR, NAND, NOR, inverter, and buffer. All inputs can be connected directly to VCC or GND. Inputs can be driven by 3.3V or 5V devices, allowing these devices to be used as level translators in mixed 3.3V and 5V environments. The device is fully specified for partial power-down applications using IOFF. The IOFF circuit disables the outputs when the device is powered down, preventing potentially harmful backflow current from flowing through the device.
Key features
- Wide supply voltage range: 1.65V to 5.5V
- Input overvoltage tolerance up to 5.5V
- High noise immunity
- ±24 mA output drive capability (VCC = 3.0 V)
- CMOS low power consumption
- Latch-up performance exceeds 200 mA
- Direct TTL-level interface compatible
- IOFF circuit supports partial power-down mode operation
- JEDEC standards compliant: JESD8-7 (1.65 V to 1.95 V), JESD8-5 (2.3 V to 2.7 V), JESD8B/JESD36 (2.7 V to 3.6 V)
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3B exceeds 8000 V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
- Multiple package options
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 74LVC1G57GW#C52953356MDD(Microdiode Semiconductor) · SOT-363 | MDD(Microdiode Semiconductor) | SOT-363 | 2,650 | ₹14.61 · 2,650 in stock | View |
