BUK7Y7R6-40EX
N-Channel 40V 79A 94.3W LFPAK56(PowerSO-8)
LFPAK56(PowerSO-8)ROHS3 CompliantActive
MOSFET N-CH 40V 79A LFPAK56(PowerSO-8)
- Manufacturer
- Nexperia
- Manufacturer part #
- BUK7Y7R6-40EX
- Store part #
- C179356
- Package / case
- LFPAK56(PowerSO-8)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,436 in stock
#C179356
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹82.78 | ₹82.78 |
| 10+ | ₹65.83 | ₹658.30 |
| 30+ | ₹57.37 | ₹1,721.10 |
| 100+ | ₹49.11 | ₹4,911.00 |
| 500+ | ₹44.11 | ₹22,055.00 |
| 1,500+ | ₹41.50 | ₹62,250.00 |
1 × ₹82.78
₹82.78
excl. GST
₹97.68 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
BUK7Y7R6-40EX
₹82.78 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 330pF
- Current - Continuous Drain(Id)
- 79A
- Ciss-Input Capacitance
- 1.65nF
- Pd - Power Dissipation
- 94.3W
- Reverse Transfer Capacitance (Crss)
- 235pF
- RDS(on)
- 7.6mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 26.2nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.08 g
Overview
Standard level N-channel MOSFET in an LFPAK56 (Power SO8) package using TrenchMOS technology. This product has been designed and qualified to AEC Q101 standard for use in high performance automotive applications.
Applications
- 12 V Automotive systems
- Motors, lamps and solenoid control
- Transmission control
- Ultra high performance power switching
Key features
- Q101 compliant
- Repetitive avalanche rated
- Suitable for thermally demanding environments due to 175 °C rating
- True standard level gate with VGS(th) rating of greater than 1V at 175 °C
