VISHAYDatasheet (PDF)
SS2P3-M3/84A
1 Independent 30V 550mV@2A 2A DO-220AA Single Diodes RoHS
DO-220AAROHS3 CompliantActive
- Manufacturer
- VISHAY
- Manufacturer part #
- SS2P3-M3/84A
- Store part #
- C3009101
- Package / case
- DO-220AA
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
30 in stock
#C3009101
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹69.17 | ₹69.17 |
| 10+ | ₹54.64 | ₹546.40 |
| 30+ | ₹48.57 | ₹1,457.10 |
| 100+ | ₹40.76 | ₹4,076.00 |
| 500+ | ₹37.30 | ₹18,650.00 |
| 1,000+ | ₹35.35 | ₹35,350.00 |
1 × ₹69.17
₹69.17
excl. GST
₹81.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SS2P3-M3/84A
₹69.17 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 30V
- Voltage - Forward(Vf@If)
- 550mV@2A
- Reverse Leakage Current (Ir)
- 150uA@30V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.148 g
Overview
Applications
- For use in low-voltage high-frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.
Key features
- Ultra-thin design, typical height 1.0mm
- Compatible with automated pick-and-place assembly
- Low forward voltage drop, low power dissipation, high efficiency
- Low thermal resistance
- MSL Level 1 per J-STD-020, lead-free peak reflow temperature 260°C
- AEC-Q101 qualified versions available
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SS2P4HM3/84A#C467996VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | 2,230 | ₹17.90 · 2,230 in stock | View |
 | SS2P4-M3/84A#C222485VISHAY · SMP(DO-220AA) | VISHAY | SMP(DO-220AA) | 3 | ₹28.29 · 3 in stock | View |
 | SS3P4HM3/84A#C3039717VISHAY · DO-220AA | VISHAY | DO-220AA | 682 | ₹41.21 · 682 in stock | View |
 | SS3P4-M3/84A#C968653VISHAY · SMP(DO-220AA) | VISHAY | SMP(DO-220AA) | 875 | ₹31.92 · 875 in stock | View |
 | SS2P3L-M3/84A#C3758734VISHAY · DO-220AA(SMP) | VISHAY | DO-220AA(SMP) | 2,647 | ₹56.85 · 2,647 in stock | View |
